Collection: MIL-DTL-5015
MIL-DTL-5015: Military Standard, Heavy-Duty, Circular Connectors.
The MS-numbers below follow the MIL-DTL-5015 standard.
Solder Contact Connectors (MS3100 Series)
- MS3100 (wall mount receptacle)
- MS3101 (cable connecting plug)
- MS3102 (box mount receptacle)
- MS3103 (potting receptacle)
- MS3105 (dummy receptacle)
- MS3106 (straight plug)
- MS3107 (quick disconnect plug)
- MS3108 (90° angle plug)
Front Release, Crimp Contact Connectors (MS3400 Series)
- MS3400 (wall mount receptacle)
- MS3401 (cable connecting receptacle)
- MS3402 (box mount receptacle)
- MS3404 (jam nut receptacle)
- MS3406 (plug)
- MS3408 (90° angle plug)
- MS3409 (45° angle plug)
- MS3412 (wall mount receptacle)
Rear Release, Crimp Contact Connectors (MS3450 Series)
- MS3450 (wall mount receptacle)
- MS3451 (cable connecting receptacle)
- MS3452 (box mount receptacle)
- MS3454 (jam nut receptacle)
- MS3456 (straight plug)
- MS3459 (straight plug, self-locking)
The following VG-number does not follow the military standard, but is intermateable with the MIL-DTL-5015 connectors.
Reverse Bayonet Connectors (AS95234/ VG95234)
- AS95234/1 (in-line receptacle)
- AS95234/2 (box mount receptacle, front panel)
- AS95234/3 (box mount receptacle, back panel)
- AS95234/4 (wall mount receptacle, front panel)
- AS95234/5 (wall mount receptacle, back panel)
- AS95234/6 (straight plug)
- AS95234/7 (jam nut receptacle)
- AS95234/8 (jam nut receptacle witch accessory threads)
- AS95234/9 (straight plug, EMI/RFI)
- AS95234/13 (thru-bulkhead receptacle)
