Smart-UPS for Shipboard Applications

We are proud to offer Smart-UPS's for Shipboard Applications, manufactured by APC by Schneider.

In the dynamic world of maritime operations, reliability, resilience, and rapid response are crucial elements for success. To meet the unique challenges faced by marine and shipboard environments, APC by Schneider Electric introduces a cutting-edge solution - the Smart-UPS for Shipboard Applications. Tailored specifically for mobile applications, these uninterruptible power supplies (UPS) are designed and engineered to deliver clean, reliable, and battle-ready performance in the most demanding scenarios.

Features

Dual Pole Circuit Breaker - Provides enhanced protection in shipboard environments
Master Kill and Battle Reset Switch - Provides quick access and control of the UPS in case of an emergency
Disabled Site Wiring Fault - Accommodates for resistances greater than 1 m Ohm between the AC line and ground in shipboard environments
Switched Outlet Group* - Controlled separately from the UPS for discrete reboot of hung devices, sequenced ON/OFF, and non-critical load shedding
SmartSlot™ Interface** - Accepts a wide array of accessory cards for advanced management and environmental monitoring
Configurable, Multi-lingual LCD Display - Provides UPS status and key measures at a glance. Clear and accurate, menu-driven display for easy set-up and customization with or without software installation
Extended-range Automatic Voltage Regulation - Provides enhanced brownout protection, boosting incoming voltage up to 30% without using battery power
Display - Intuitive, easy-to-use LCD Interface

* Only for SMT1500X93, SMT1500RMX93, SMX3000RMX93

** Only for SMX3000RMX93

Technical Specifications

	SMT750X93	SMT1500X93	SMT1500RMX93	SMX3000RMX93
Output
Output power capacity	500 Watts / 750 VA	1000 Watts/ 1440 VA		2700 Watts/3000 VA
Nominal output voltage	120V
Output voltage distortion	Less than 5% at full load
Output frequency (sync to mains)	50/60 Hz +/- 3 Hz (auto sensing)
Waveform type	Sine Wave
Output connections	(6) NEMA 5-15R	(8) NEMA 5-15R	(6) NEMA 5-15R	(6) NEMA 5-15R (3) NEMA 5-20R
Efficiency at full load	90%

Input
Nominal input voltage	120V
Input frequency	47 - 63 Hz +/- 3 Hz (auto sensing)
Input connections	NEMA 5-15P			NEMA L5-30P
Input voltage range (full load)	82V 144V			65V - 153V

Batteries and runtime
Battery type	Maintenance-free, sealed lead-acid battery, leak proof
Extended battery capability	No			Yes
Runtime (at full load half load)	5 mins / 15 mins	5 mins / 17 mins	7 mins / 26 mins	5 mins* / 15 mins*

Communications and management
Interface port(s)	Serial (RJ45), USB 2,0
SmartSlot™ interface availability	No			Yes
Control panel	LCD interface with quick status indicators
EPO	No			Yes
Disabled site wiring fault	Yes

Physical
Rack height	-	-	2U	4U
Net HxWxD (mm)	161 x 138 x 369	219 x 171 x 439	86 x 432 x 477	178 x 432 x 483
Net weight (lbs.)	27.6	54.2	58.4	85.19
Color	Black

Environmental
Operating environment	32 - 104 °F (0 - 40 °C)
Operating relative humidity	0 - 95%, non-condesending
Operating elevation	0-10000 feet (0-15000 meters)
Storage temperature	-4 131 °F (-20 - 55°C) short term storage
Storage relative humidity	0 - 95%, non-condesending
Storage elevation	0-50000 feet (0-15000 meters)
Audible noise at 1 meter	< 41 dBA	< 45 dBA		< 55 dBA

Conformance
Regulatory approvals	UL1778, CSA 22.2 No. 107.1, FCC Part 15B, cULus
Standard Warranty	3-years electronics and 2-years battery
